YZDL734 【100W~360W】

The luminaire adopts the photoelectric separation design,
the vertical heat dissipation technology, prolongs the service life,
maximally enhances the heat dissipation efficiency.
 Constant current drive, standard module as the core component,
module with plug and pull type waterproof connector connection,
easy to replace the module.
The power supply comes with 4KV/6KV anti-surge. High index finger,
low glare, polychromatic temperature, low stroboflash.
Availability:

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button


SPECIFICATION                    YZDL734
Input Power  100W~120W   150W~180W   200W~240W   280W~300W   320W~360W
Beam Angle

TYPE I / TYPE II / TYPE III / TYPE IV
Color Temp.                                                          3000K/4000K/5000K/5700K
System Efficiency 110-170LM/W
CRI ≥70
Voltage 100-277V
Power Factor 0.95
Housing Aluminum Die-casting
Diffuser Lens
Working Temp. -30℃~+50℃
IP grade IP66
IK IK08
Optional

SPD/ Photocell/ Motion sensor/ NEMA
LED Life Span（L70/B50） >60000 hours


734-02

路灯-模组-01


YZDL734
