YZDL759 【40W~200W】

Die casting aluminum lamp body, integral PC lens.
 IP66,IK08.
 Suitable for Φ60 horizontal installation.
 NEMA at request.
SPD at request.
Availability:

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button


SPECIFICATION                    YZDL759
Input Power    40W~60W           80W~120W            150W~200W
Beam Angle TYPE III
Color Temp.                                                          3000K/4000K/5000K/5700K
System Efficiency 110-150LM/W
CRI ≥70
Voltage 100-277V
Power Factor 0.95
Housing Aluminum Die-casting
Diffuser Lens
Working Temp. -30℃~+50℃
IP grade IP66
IK IK08
Optional SPD/Phonecell/NEMA
LED Life Span（L70/B50） >60000 hours

759-02

759配光-11



YZDL759
