YZDL789 【60W~300W】

Die-casting Aluminum body combined with Aluminum LED Modules,flexible combination.
Excellent performance of wind speed withstand 150Km/h.
High transmittance PC diffuser,10% higher system efficiency.
Automatic rainwater cleaning to avoid leaves accumulation.
Installation: Horizontal.
Main/secondary roads,parks,city squares,districts,etc.
Availability:

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button


SPECIFICATION YZDL789
Input Power    60W~180W        200W~300W
Beam Angle

TYPE I / TYPE II / TYPE III / TYPE IV
System Efficiency 110-170LM/W
Color Temp. 3000K/4000K/5000K/5700K
CRI ≥70
Voltage 100-277V
Power Factor 0.95
Housing Aluminum Die-casting
Diffuser Lens
Working Temp. -30℃~+50℃
IP grade IP66
IK IK08
Optional SPD/ Photocell/ Motion sensor/ NEMA
LED Life Span（L70/B50） >60000 hours


789-02

路灯-模组-01


YZDL789
